Mobile extraction unit JUMBO Filtertrolley 2.0

Elegant device with castors, telescopic handle and extraction arm

Product details

Benefits of the JUMBO Filtertrolley

  1. Low-noise operation

    ULT's extraction and filtration systems are particularly quiet. This has already been appreciated by numerous customers worldwide. Your employees are thus effectively protected against noise pollution.

  2. High flexibility

    Our extraction and filtration systems can be used flexibly. This lets you choose, for instance, between mobile and/or stationary solutions, integrated systems, or specialized ventilation solutions. If necessary, the optimal application can be configured by ULT experts on-site.

  3. Ideal filtration technology

    The utilization of the most sensible filtration technology ensures a long filter service life and, consequently, reduces maintenance and spare parts costs. ULT always offers You the ideal solution for your specific pollutant technology in order to achieve the best possible filtration results.

  4. Simple operation

    Our extraction and filtration systems have been designed in such a way that they can be put into operation trouble-free and are easy to operate. They are easy to operate, handle and maintain.

  5. Low energy consumption

    Our extraction systems reduce operating and maintenance costs due to their optimal filter concept. In addition, the system is designed in such a way that it keeps the required energy consumption extremely low.

  6. Functional design

    You can use this unit either standing upright or lying. It, however, easily fits under or aside to a working table.

Technical specifications

Device versionJUMBO Filtertrolley 2.0
Max. air flow in m³/h190
Max. vacuum in Pa3200
Nominal capacity in m³/h@Pa80 @ 1900
Dimensions in mm (WxDxH)450x340x530
Weight in kg36
Noise level in dB49
Connection variants – diameter in mm1 X 50 / Option: 1 X 75
Find more on mobile fume extraction and JUMBO device versions!

Mobile fume extraction with the JUMBO Filtertrolley

Downloads

  1. Technical documentation JUMBO Filtertrolley
  2. Accessories JUMBO Filtertrolley
  3. Brochure "Mobile fume extractor JUMBO Filtertrolley"
Images
Side view of the white-grey unit with extendable handle
For laboratory use: JUMBO LabCat with flat hood on extraction arm
Blue-grey device with castors for mobile extraction
Mobile dust extractor JUMBO ASD with DN 75 extraction arm
Blue-grey system with device rollers and extraction arm
Typical solder fume extraction: JUMBO LRA with movable extraction arm
Side view of the white-grey unit with extendable handle
For laboratory use: JUMBO LabCat with flat hood on extraction arm
A black flat hood is mounted on an extraction arm
JUMBO Filtertrolley LAS for mobile laser fume extraction
White suction arm with tip installed on a white appliance
Extraction arms for special applications, e.g. for corrosive gases
Blue-grey device with mounted suction arm with suction gap
Restorers appreciate the quiet operation of the JUMBO Restauro
Side view of the white-grey unit with extendable handle
For laboratory use: JUMBO LabCat with flat hood on extraction arm
Blue-grey device with castors for mobile extraction
Mobile dust extractor JUMBO ASD with DN 75 extraction arm
Blue-grey system with device rollers and extraction arm
Typical solder fume extraction: JUMBO LRA with movable extraction arm
Side view of the white-grey unit with extendable handle
For laboratory use: JUMBO LabCat with flat hood on extraction arm
